Multi-Layer FPC

  • Advanced flexible circuit board for high-density and high-performance designs.

Overview

Multi-Layer FPC

Multilayer FPC is suitable for high-density, high-performance applications. It has many conductive layers, good electrical performance, and durability in difficult conditions.

Other FPC Categories

Multilayer FPC features

Multi-Layer FPC2

Key Features

  • High-density wiring suitable for complex circuits.
  • Superior electrical performance for high-speed signals.
  • Reliable even in tough settings.
Multi-Layer FPC Application

Applications

  • Medical Equipment: Highly accurate diagnostic devices.
  • Industrial Automation: Robots and Control Systems.
  • Aviation Aerospace: Satellite communication equipment.

Technical specifications

Parameter

Specification

Layers

3-10 layers

Thickness

0.2mm – 0.6mm

Conductor Material

Copper Foil (18μm/35μm/70μm)

Min Line Width/Spacing

0.05mm/0.05mm
